Canvas Particles JS

A smooth, highly efficient customizeable particle renderer

Installation

  • npm

    View the package on npm: canvasparticles-js.

    NPM downloads
    Console
    $ npm install canvasparticles-js

    ES Module import

    ESM
    import CanvasParticles from 'canvasparticles-js'

    If you don't have a bundler:

    ESM
    import CanvasParticles from './node_modules/canvasparticles-js/dist/index.mjs'

    Global import

    HTML
    <script src="./node_modules/canvasparticles-js/dist/index.umd.js" defer></script>

    No import required in each JavaScript file!

Start animating

Documentation: README.md

Options documentation: README.md#options

JavaScript
const selector = '#my-canvas'
const options = {}
new CanvasParticles(selector, options).start()

Showcase

Default

Instantiation of the CanvasParticles class with the default options.

JavaScript
const showcaseDefault = new CanvasParticles('#showcase-default').start()

Start and stop the animation.

Stop
showcaseDefault.stop()
Stop (no clear)
showcaseDefault.stop({clear: false})
Start
showcaseDefault.start()

Coloring

Setting the canvas and the particle colors.

JavaScript
new CanvasParticles('#showcase-coloring', {
  // Any CSS Supported value for the 'background' property
  background: 'rgb(21, 16, 25)',
  particles: {
    // Any CSS Supported color
    color: 'hsl(206, 100%, 77%)',
  },
}).start()

Interaction

Choose how the mouse can interact.

Info Setting mouse.distRatio below 1 allows particles to stick.

Important When using Stick, set particles.maxWork below 30 to prevent performance drops when collecting all particles in one place.

JavaScript
new CanvasParticles('#showcase-interact', {
  mouse: {
    interactionType: 2,
    connectDistMult: 0.8,
    distRatio: 0.7,
  },
  particles: {
      maxWork: 20,
  },
}).start()

Quantity

Define the amount of particles by setting particles.ppm.

Info ppm = Particles Per Million pixels the canvas covers.

JavaScript
new CanvasParticles('#showcase-quantity', {
  particles: {
    ppm: 2000,
    max: 4000,
    connectDistance: 50,
  },
}).start()

Connect distance

Define the maximum length of a connection.

JavaScript
new CanvasParticles('#showcase-connect-distance', {
  background: 'linear-gradient(100deg, #f80, #0f8 150%)',
  mouse: {
    interactionType: 2,
    connectDistMult: 0.4,
  },
  particles: {
    connectDistance: 400,
  },
}).start()

Movement

Customize the movement of the particles.

JavaScript
new CanvasParticles('#showcase-movement', {
  particles: {
    relSpeed: 3,
    relSize: 2,
    rotationSpeed: 40,
  },
}).start()

Pushing Gravity

Important Gravity requires heavy calculations.

JavaScript
new CanvasParticles('#showcase-pushing-gravity', {
  particles: {
    connectDistance: 175,
  },
  gravity: {
    repulsive: 3,
    fricion: 0.995,
  },
}).start()

Pulling Gravity

Also requires repulsive gravity to avoid forming a singularity.

JavaScript
const showcasePullingGravity =
new CanvasParticles('#showcase-pulling-gravity', {
  mouse: {
    interactionType: 2,
    distRatio: 1,
  },
  particles: {
    maxWork: Infinity
    relSpeed: 0,
  },
  gravity: {
    repulsive: 8.25,
    pulling: 3,
  },
})
Reset
showcasePullingGravity.newParticles()
Prevent heavy load
showcasePullingGravity.option.particles.maxWork = 12

Hue Rotation Effect

Use JavaScript to edit options on the fly.

JavaScript
const showcaseHueRotation =
new CanvasParticles('#showcase-hue-rotation', {
  background: 'var(--bg)',
  particles: {
    color: 'hsl(0, 100%, 50%)'
  },
}).start()
Rotate hue
setInterval(() => {
  const color = `hsl(${hue++}, 100%, 50%)`
  hue %= 360
  showcaseHueRotation.setParticleColor(color)
}, 20)

Multiple Colors

Overlap multiple <canvas> elements using CSS and initialize each one seperately.

JavaScript
new CanvasParticles('#showcase-multiple-colors-1', {
  background: 'black',
  particles: {
    color: 'yellow',
  },
}).start()

new CanvasParticles('#showcase-multiple-colors-2', {
  background: 'transparent',
  particles: {
    color: 'aqua',
  },
}).start()

Sandbox

Presets

Persistent workspaces

JavaScript (editable)






          Options documentation:

            README.md#options












Information







Handling particles beyond canvas bounds



            Particles are only drawn if they are within the visible area of the canvas, accounting for their size.
            Particles are
            considered to still be visible if their edges are within the canvas bounds, preventing large particles from
            disappearing when
            their center crosses the edge.



When particles move beyond the floating area bounds, they will teleport to the opposite side.



Handling particle connections beyond canvas bounds



            The floating area for the particles is larger than the canvas bounds to ensure no lines between particles
            will suddenly
            dissapear near the edges. The floating space added to all 4 sides is exactly equal to the maximum length of
            a line, defined
            with option.particles.connectDist.



By default, a line is not drawn between particles if both are outside the visible canvas area.



            Each particle's grid position is calculated based on its location relative to the visible canvas area. This
            allows for
            determining whether two particles, even when outside the canvas, should have a connecting line drawn between
            them because part
            of it can still be seen.




Performance optimizations



            Canvas Particles JS is a highly optimized particle renderer (ignoring the fact that it's coded in
            JavaScript 😭). A lot of time has gone into profiling the code and improving efficiency on expensive tasks.





  •

    The heaviest task of the animation loop is processing and assigning a new color to
                ctx.fillStyle for every single line being drawn, every frame, but the
                only
                difference between these colors is the opacity. Profiling shows that keeping
                ctx.fillStyle the same and only changing
                ctx.globalAlpha is about 25x faster.



    •

  •


                An IntersectionObserver is used to pause and resume the animation when
                the canvas enters or leaves the viewbox.



    •

  •


                A ResizeObserver is used to handle canvas as it's more efficient than
                using events and it removes most forced reflow overhead. This makes resizing roughly 18x faster based on
                benchmarks.



    •

  •

    Particles smaller than one pixel are drawn as squares instead of circles which is ±183% faster.


    •




Benchmark limits



After many improvements, the benchmark is able to handle
            ridiculously large numbers in seconds (device dependent):





Particles at once (depends on memory limit)








Total canvas area in pixels








Canvas elements



              Over
